ALPINE SWR-1542D

Alpine

15" (38cm) Subwoofer (4Ohm+4Ohm)

109 900 Ft
Mennyiség

Leírás

SWR-1542D - 15" (38cm) Subwoofer (4Ohm+4Ohm)

Built from select materials and high-end components, designed for precision and efficiency, and protected by Thermal Management features the Type-R subwoofers provide the kind of real power and massive bass only hinted at by other speakers.

Termék információ

Initiates file downloadSWR-1522/SWR-1542 Dimension Drawing

SWR-1522/SWR-1542 Dimension Drawing

Amplifier Matching Chart

Initiates file downloadDownload Amplifier Matching Chart

Initiates file downloadRTEmagicC_subwoofer_enclosure_07_300.jpg.jpg

Initiates file downloadDownload Subwoofer Enclosures Chart

HAMR Engineering

HAMR EngineeringHAMR Engineering is a group of Alpines latest and most sophisticated speaker technologies for enormous power, tight bass, cooler operation and amazing durability. Through the use of highly advanced materials and patented (and some patent pending) design features, these subwoofers boast exceptional power handling, superb sound quality and long life.

High Amplitude Multi Roll Surround (patent pending)

High Amplitude Multi Roll SurroundMost designs sacrifice cone area for a wide surround, or sound quality for a tall surround. Our High-Amplitude Multi Roll surround avoids this compromise AND achieves superb linearity, giving the best of both worlds increased cone area for greater SPL and further linear excursion for optimum sound quality.

Kevlar Reinforced Pulp Cone

KevlarŽ Reinforced Pulp ConeReinforcing the pulp cone with Kevlar provides an ultra lightweight parabolic cone that maintains its shape even during vigorous movement. Since the cone is significantly stronger with faster response, the result is highly detailed, accurate sound reproduction and body-shaking bass.

Encapsulated Push Terminals

Encapsulated Push TerminalsWith all wires conveniently located on one side, the Type-R subwoofers can be installed quickly, easily and neatly. Jumpers are configurable for either parallel or series, and the push terminals allow for heavy gauge speaker wire.

All New Type-R Design

All New Type-R DesignSignificantly redesigned and upgraded, the Type-R subwoofers have an amazing 40% more power handling capacity over last years models, and take advantage of key technologies and design features of the high-end Type-X line for the highest possible sound quallity and performance.

Thermal Management Technology

HAMR TechnologyCooling is a crucial element in subwoofer design. Since overheating in the voice coil can severely damage the woofer cone, Type-R subs use a variety of sohpisticated techniques to ensure that airflow is effectively controlled pulling in fresh, cool air and maintaining maximum contact with all thermally conductive parts for optimum heat dissipation.

Thermal Management Technology

HAMR Engineered Airflow Cooling System

This meticulously designed system uses various techniques and technologies, many patent pending, to force air across hot components for maximum cooling effectiveness. The diagram above shows how airflow management pushes hot air out and cooler air in.

HAMR Engineered Airflow Cooling System

HAMR Engineered Thermal Management

Along with its sophisticated cooling techniques, the Type-R subwoofers use special materials to minimise heat, such as a high temperature-resistant four-layer brass voice coil winding and a high-strength BSP bobbin. The diagram above shows where heat is transferred for cooler operation.

Jellemzők és részletek

Features

  • Peak Power 2000W
  • RMS Power 750W
  • Frequency Response: 22Hz - 500Hz
  • High Excursion 1-1/4" Santoprene Edge
  • Kevlar Reinforced Pulp Cone
  • Dual Progressive Nomex Spiders with Edge Control
  • Integrated Tinsel Lead Spider Design
  • Custom Cast Aluminium Frame with Integrated Heat Transfer Plate
  • Extended Length Dual-Flared Vented Pole Design
  • High-Strength Brass Voice Coil Bobbin
  • Heavy-Duty 10cm2 Push Terminals
  • Computer Optimized Magnetic Circuit
  • Designed and Engineered in the USA

Garancia: 2 év magyarországi hivatalos forgalmazói garancia.
